China NTM8842 Lovol Tractor Clutch Release Bearing TA820.213-10

Type: Clutch Release Bearing

Designation: NTM8842 Bearing

OEM Code: TA820.213-10

Dimension: 88*132*51.5mm

Weight: 3.5kg

Materials: Chrome Steel

Materials of Cage: Nylon

Quality Grade: ABEC-1



Tractor bearings are mainly used in the field, the working environment is bad, and the continuous working time is long, which requires the bearings to be reliable in the use process, and work normally in the dusty environment,



Agricultural tractors are the work horses of the industry with drivetrain, engine, suspension and steering being key sub-systems Safety, availability and productivity are the underlying forces driving many of the industry trends, such as:

  • Automation, smart functionality and power management
  • Better efficiency which reduces frictional losses,

resulting in lower fuel costs

  • Increased power density and reliability
  • Standardization (consolidation of the powertrain)
  • Improved comfort and safety

The main types of bearings used by tractors are

— Single row tapered roller bearings

— Matched tapered roller bearings

— Inch tapered roller bearings

— Deep groove ball bearings

Clutch Release Bearings
