Large size insulated bearing 6048 M/C4S0VL0241 equipped with ceramic rolling elements

Detailed Product Description

Place of Origin: China
Brand Name:                                    CoatMaster
Quality Standard: 80% service life of SKF
Model Number:  6048 M/C4S0VL0241

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: negotiate
Packaging Details: Single box and then put in Carton or Wooden Case
Delivery Time: 5 days after confirmed
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 500 Pcs/Month

Detailed Product Description

Designation: 6048 M/C4S0VL0241 Coating: Aluminium Oxide Coating
Electrical Resistance: Voltages Up To 3000 V DC Cage: Brass
Cleance: C4H Dimension: 240×360×56 mm
Weight: 20.1 kg Factor: Electric Traction Motors

Electrically Insulated Deep groove ball bearings 6048 M/C4S0VL0241 are particularly versatile. They are simple in design, non-separable, suitable for high and very high speeds and are robust in operation, requiring little maintenance. Because deep groove ball bearings are the most widely used bearing type, they are available from XRB in many designs, variants and sizes. For railway applications, single row deep groove ball bearings are used in traction motors, mainly as the locating bearing in combination with a non-locating cylindrical roller bearing. Many modern traction motor designs require electrical insulation.

Electric Insulated Deep Groove Ball Bearing 6048 M/C4S0VL0241 consist of one inner ring, one outer ring with Aluminuim Oxide Coating, and one piece of machined brass cage, steel balls, Its dimension are the same with normal chrome steel 6048 M/C4 Deep Groove Ball Bearing.

CoatMaster 6048 M/C4S0VL0241 services ball Bearings At work in virtually every industrial process, available in every possible shape and size, gear units and drivelines face an extremely wide range of operating requirements and conditions. But regardless of industry or application, all industrial transmissions share a common set of challenges – they must perform as reliably, efficiently and cost-effectively as possible.

CoatMaster Bearing Services can help manufacturers and users alike identify ways to optimize transmission performance and reliability. Using a system approach, CoatMaster Insulated ball Bearings can help you exploit your gear unit’s full potential and drive performance and reliability in several ways:

— Increase torque

— Downsize designs

— Double service life

— Aim for 100% operational reliability

— Improve energy efficiency

— A wide range of conditions and requirements

— The growing demands of modern farming


Electrically insulated Rolling Bearings 6048 M/C4S0VL0241
Principal dimensions 240×360×56mm
Weight 20.1 kg
Basic dynamic load rating-C 255kN
Basic static load rating-Co 315kN
Fatigue load limit-Pu 0 kN
Reference speed 0 r/min
Limiting speed 3000 r/min


Product Features of Electrically Insulated Bearing

  1. High insulation properties

To prevent electric corrosion in bearings, a highly productive aluminum ceramic coating material is used to coat the outer ring, and by combining optimized additives, insulation performance is improved by about tenfold.

  1. Improved durability
  • Optimizing bearing elements improves film impact resistance by a factor of 3x.

Optimized ceramic coating materials makes for excellent heat dissipation.

XRB is the China bearing manufacturer & exporter & supplier, it can supply  6048 M/C4S0VL0241 insulated bearing, Our large quantity insulated deep groove ball bearing Stock can meet your need with good quality and fast delivery, Also you can find FAG 6048-M-J20AA-C4 Bearing, the other type and brand insulated deep groove ball bearing, insocoat tapered roller bearing, Current-Insulated Bearings.
