Detailed Product Description

Designation: 6312 M/C4VL0241 Coating: Aluminium Oxide Coating
Electrical Resistance: Voltages Up To 3000 V DC Cage: Brass
Cleance: C4 Dimension: 60×130×18 mm
Weight: 1.7 kg Application: Electric Traction Motors

Electric Insulated Deep Groove Ball Bearing 6312 M/C4VL0241 provide a bearing function and electrical insulation, virtually eliminates premature bearing failure caused by stray electric currents, electrical insulated bearing can reduce the number of failures and improve the machine uptime, reduce the cost of maintenance.

CoatMaster Bearing Services can help manufacturers and users alike identify ways to optimize transmission performance and reliability. Using a system approach, CoatMaster services 6312 M/C4VL0241 insolated Bearings can help you exploit your gear unit’s full potential and drive performance and reliability in several ways:

Increase torque

Downsize designs

Double service life

Aim for 100% operational reliability

Improve energy efficiency

A wide range of conditions and requirements

The growing demands of modern farming

Size, location, elevation, climate, soil structure and crop rotation make every farm unique. But every farm’s equipment endures many of the same challenging conditions. Mud, dust and debris. Extreme heat and cold. Rain and runoff. Corrosive chemicals. Long periods of inactivity, then intense periods of work. Rising fuel costs and new environmental regulations only complicate matters.

Electrically insulated Rolling Bearings 6312 M/C4VL0241
Principal dimensions 60×130×31mm
Weight 1.7 kg
Basic dynamic load rating-C: 81.9kN
Basic static load rating-Co: 52kN
Fatigue load limit-Pu: 0 kN
Reference speed: 15000 r/min
Limiting speed: 10000 r/min
Electrically Insulated Rolling Bearing as a Preventive Measure
As a rule, it is very difficult to eliminate the causes of bearing voltages that are induced by the motor. Nevertheless, it is possible to avoid damage to the bearing, if the flow of current can either be prevented or at least significantly reduced. Many types of Electrically Insulated Bearing are available today for this very purpose.

The Electrically Insulated Bearing adopts the special spraying process, spraying the high quality coating on the outer surface of the bearing, Strong adhesion between film and substrate, Good insulation performance, avoiding the electric corrosion effect of the induced current on the bearing, Prevent current from damage for grease, rolling elements and raceways, Improve the service life of bearings . The process is constantly being improved.

XRB is the China bearing manufacturer & exporter & supplier, it can supply 6312 M/C4VL0241 bearing, Our large quantity insulated deep groove ball bearing Stock can meet your need with good quality and fast delivery, Also you can find FAG 6312-M-J20AA-C4 Bearing, the other type and brand insulated deep groove ball bearing, insocoat tapered roller bearing, Current-Insulated Bearings.
